| Model | SG24100 | SG24150 | SG24200 | SG48100 | SG48150 | SG48200 |
| Specification | 25.6V100Ah | 25.6V150Ah | 25.6V200Ah | 51.2V100Ah | 51.2V150Ah | 51.2V200Ah |
| CellCombination | 8S1P | 8S1P | 8S1P | 16S1P | 15S1P | 16S1P |
| Battery Pack Capacity | 2.56kWh | 3.84kWh | 5.12kWh | 5.12kWh | 7.68kWh | 10.24kWh |
| Standard Discharge Current | 50A | 50A | 50A | 50A | 50A | 50A |
| Max Discharge Curre nt | 100A | 100A | 100A | 100A | 105A | 105A |
| Working Voltage Range | 20-292VDC | 20-29.2VDC | 20-29.2VDC | 43.2-57.6VDC | 40.5-54VDC | 43.2-57.6VDC |
| Standard Voltage | 25.6VDC | 25.6VDC | 25.6VDC | 51.2VDC | 51.2VDC | 51.2VDC |
| Max Charging Current | 50A | 50A | 50A | 50A | 105A | 105A |
| Max Charging Voltage | 57.6V | 57.6V | 54V | 57.6V | 54V | 57.6V |
| Discharge Depth &Life | ≥6000 cycles(0.5C@25℃),Energy retention>80% | |||||
| Working Humid ity | 65±20%RH | |||||
| Operating Temperature | -10~+50℃ | |||||
| Working Altitude | ≤2500m | |||||
| Fire Protection | Aerosol PACK12g | |||||
| Cooling Method | Natura cooling | |||||
| Installation Method | Wall Mounted | |||||
| International Protection | IP20 | |||||
| Max Parallel Units | 15PCS | |||||
| Communication Method | RS485/RS232/CAN/WiFi | |||||
| Certifications | CE,ROHS,FCC,UN38.3,MSDS,ISO9001 | |||||
| Product Size(mm) | 440*460*170 | 440*385*170 | 440*585*170 | 440*585*170 | 440*585*230 | 540*800*170 |
| Package Size(mm) | 500*520*230 | 500*445*230 | 500*630*240 | 500*630*240 | 500*630*290 | 600*850*240 |
| Net We ight(kg) | 26.5 | 36.5 | 46 | 46 | 64 | 85 |
| Gross Weight(kg) | 32 | 38 | 54 | 54 | 72 | 92 |
|
|
