| Model | LA12100 | LA12200 | LA12300 | LA2450 | LA24100 | LA24200 |
| Battery | ||||||
| Specification | 12V100AH | 12V200AH | 12V300AH | 24V50AH | 24V100AH | 24V200AH |
| Capacity | 1.28KWh | 2.56KWh | 3.84KWh | 1.28KWh | 2.56KWh | 5.12KWh |
| Standard Discharge Current | 50A | 50A | 50A | 25A | 50A | 50A |
| Max. Discharge Current | 100A | 100A | 100A | 50A | 100A | 100A |
| Working Voltage Range | 10-14.6V | 10-14.6V | 10-14.6V | 20-29.2V | 20-29.2V | 20-29.2V |
| Standard Voltage | 12.8V | 12.8V | 12.8V | 25.6V | 25.6V | 25.6V |
| Max. Charging Voltage | 14.6V | 14.6V | 14.6V | 29.2V | 29.2V | 29.2V |
| Cycle Life | 3000~6000 cycles @ DOD 80%/25°C/0.5C | |||||
| Working Humidity | 65±20%RH | |||||
| Operating Temperature | -10~+50°C | |||||
| Working Altitude | ≤2500m | |||||
| Cooling Method | Natural cooling | |||||
| General Information | ||||||
| Product Size | 255*165*215mm | 480*165*240mm | 515*235*225mm | 305*165*215mm | 480*165*240mm | 635*245*220mm |
| Net Weight | 16Kg | 28Kg | 45Kg | 20Kg | 30Kg | 40Kg |
| Permissible Altitude (m) | <4000m (>2000m derating) | |||||
| IP Rating | IP21 | |||||
| Working Temperature (℃) | -20-60 | |||||
| Relative Humidity | 0-95%, no condensation | |||||
| Warranty | 3 years | |||||
| Installation Type | Portable | |||||
| Certification | IEC62619/EN61000-6-1/EN61000-3/RoHS/UN38.3 | |||||
|
|
